Towards sex identification of Asian Palmyra palm (Borassus flabellifer L.) by DNA fingerprinting, suppression subtractive hybridization and de novo transcriptome sequencing

Plant materials

For DNA isolation, young leaves were collected from mature palm plants with known sexes from various locations in three regions of Thailand: the southern region (Song-Khla and Surat-Thani provinces), the central region (Phachinburi, Phetchaburi, Pathum-Thani, Nakon-Pathom, Kanchanaburi, Nakhon-Sawan and Chainat provinces) and the northeastern region (Nakhon-Ratchasima, Burirum, Ubon-Ratchathani, Kalasin and Amnat-Charoen provinces). For RNA isolation, male and female inflorescences were collected from the southern region (Song Khla province) and the central region (Nakon-Pathom province).

Nucleic acid isolation

Total DNA was isolated from young leaves using a modified method based on the CTAB method as described previously in Pipatchartlearnwong et al. (2017a) and Pipatchartlearnwong et al. (2017b). Total RNA was isolated from young inflorescences (see Fig. 1) using the modified CTAB method. Briefly, the sample was pulverized into fine powder in liquid N₂ by using a mortar and pestle and mixed with CTAB extraction buffer [2% (w/v) CTAB, 100 mM Tris-HCl pH.8, 20 mM EDTA and 1.4 M NaCl, 2% (w/v) polyvinylpyrrolidone-90 and 2% (v/v) β-mercaptoethanol]. RNA was then precipitated using 1/3 volume of 10 M LiCl at −20 °C for overnight and then centrifuged at 11, 750 × g at 4 °C for 30 min. Total RNA was treated with DNase I (New England BioLabs^®Inc., Ipswich, MA, USA) at 37 °C for 30 min followed by phenol: chloroform extraction and ethanol precipitation. RNA quality and quantity were analyzed by agarose gel electrophoresis and NanoDrop (Thermo Scientific, Waltham, MA, USA).

DNA fingerprinting

The RAPD-based OPA-06 marker was conducted according to George et al. (2007) using total DNA from 20 male and 20 female samples. AFLP analysis was performed using 26 male and 46 female samples by, firstly, restriction digestion of 250 ng total DNA using EcoRI and MseI (Thermo Fisher Scientific, USA) and adaptor ligation. And, secondly, pre-selective amplification was performed in a 25 µl reaction volume containing 2 µl of the digested DNA, 5 mM dNTPs, 40 mM MgCl2, 5 ρM of each MseI adaptor+C and EcoRI adaptor+A primers and 1 unit of Taq DNA polymerase (Vivantis, Malaysia) using the conditions as follows: 20 cycles of 94 °C for 30 s, 56 °C for 1 min and 72 °C for 1 min, with a final extension step at 72 °C of 5 min. The reaction was diluted 20-fold using dH₂O before being used in a selective amplification reaction: 25 µl total volume containing 5 µl of the diluted DNA, 4 mM dNTPs, 40 mM MgCl2, 5 ρM MseI+3 and 5 ρM of EcoRI+3 primers (Table S1) and 1 unit of Taq DNA polymerase using a touch-down condition (12 cycles of 94 °C for 30 s, 65 °C (−0.7 °C/cycle) for 30 s and 72 °C for 1 min, followed by 23 cycles using the annealing temperature at 56 °C). SCoT was performed using cDNA from four male and four female samples. SCoT primers were based on Collard & Mackill (2009) (Table S2). The PCR reaction was performed in a 20 µl volume, which included 50 ng of DNA, 4.8 mM dNTPs, 30 mM MgCl2, 20 ρM SCoT primer and 1 unit of Taq polymerase (Vivantis, Malaysia) using 35 cycles of 94 °C for 1 min, 50 °C for 1 min and 72 °C for 2 min, with a final extension for 5 min. The modified SCoT method was performed by mixing SCoT primers with primers from polyA, EST-SSRs of oil palm and transposon element (TE) markers (Tables S3 and S4) (Bureau & Wessler, 1994; Takata, Kishima & Sano, 2005). ILP marker based on Ukoskit & U-thoomporn (2016) (Table S5) was performed using total DNA from three male and three female samples. Each PCR reaction were performed in a 20 µl volume containing 20 ng of DNA, 4 mM dNTPs, 75 mM MgCl2, 3.5 ρM for each primer and 0.5 unit of Taq polymerase (Vivantis, Selangor, Malaysia) using 35 cycles of 94 °C for 30 s, 56 °C for 1.30 min and 72 °C for 30 s, with a final extension for 5 min. EST-SSR and gSSR microsatellite markers (Table S6 and S7, based on Arabnezhad et al., 2012; Billotte et al., 2004; Elmeer et al., 2011; Pipatchartlearnwong et al., 2017a; Pipatchartlearnwong et al., 2017b) were performed using total DNA from four males and four female samples using the same PCR condition as above. PCR products for RAPD, SCoT and ILP were resolved in 2% (w/v) agarose gel electrophoresis and visualized under ultraviolet (UV) light after staining with ethidium bromide. Those for AFLP, SCoT+EST-SSR, SCoT+TEs, EST-SSR and gSSR were resolved in 6% (w/v) polyacrylamide gel electrophoresis and visualized by silver staining.

Suppression subtractive hybridization (SSH)

Total RNA from one male and one female inflorescence samples from Song Khla province were used in the study (Figs. 1G–1H). The first-strand and double strand cDNA was synthesized from 1 µg of total RNA samples using the SMART cDNA Library Construction Kit (Clontech Laboratories Inc., Palo Alto, CA, USA) following to the manufacturer protocol. Double-strand cDNA of male and female was labeled with biotin-16 dUTP using nick translation: 100 µl total volume containing 400 ng of double-strand cDNA, 3.96 mM of dGTP, dATP and dCTP, 1.6 mM of dTTP, 2.4 µl of biotin-16 dUTP (Sigma-Aldrich), 48 µM of 5′PCR PrimerII A (5′-AGCAGTGGTATACAACGCAGAGT-3′), 10x Taq buffer, and 5 unit of Taq polymerase (Vivantis, Selangor, Malaysia) using 40 cycles of 94 °C for 15 s, 65 °C for 30 s, and 68 °C for 6 min. The biotin-16 dUTP labeled cDNA was checked for its detection signal using dot blot hybridization at least at 10⁻⁴ dilution. First-strand cDNA of male and female cDNA was subtracted using labeled double-strand cDNA of its opposite sex at ratio 1:3 following a method from Rebrikov et al. (2004). Subtracted samples were purified by ethanol precipitation, and double-strand cDNA was synthesized by PCR reaction containing 2 µl of subtracted cDNA, 48 µM of 5′ PCR PrimerII A, 10 mM dNTPs, 5x NEB polymerase buffer and 5 unit of Q5^® High-Fidelity DNA polymerase (New England Biolabs) through 21 cycles of 94 °C for 15 s, 65 °C for 30s and 68 °C for 6 min. Subtracted double-strand cDNA was purified and ligated into pGEM-Teasy (Promega). Clones were selected by blue-white colony section and screened using colony PCR for > 500 bp inserted fragment, before re-selection using dot blot hybridization I and II using probes from opposite sexes. Selected clones were sequenced and analyzed against GenBank using BLAST.

Transcriptome analysis

Transcriptome sequencing was performed by Macrogen Inc. (Republic of Korea) using 10 µg of total RNA. Total RNA was obtained from two male (MY and MO) and two female (FY and FO) inflorescence samples from Nakon-Pathom province (Figs. 1I–1J). Briefly, cDNA libraries were constructed using the TruSeq™ RNA sample preparation kit (Illumina, USA) and sequenced on a HiSeq 2000 (Illumina, USA) with paired-end 100 bp read lengths. Initial raw reads were trimmed and filtered with FastQC (http://www.bioinformatics.babraham.ac.uk/projects/fastqc) and Trimmomatic version 0.32 (http://www.usadellab.org/cms/?page=trimmomatic) software to eliminated low-quality reads (quality score lower than 20) and remove adapters. Reads were considered as high quality if more than 70% of the bases had Phred values more than Q20. Reads produced from this study were assembled by Trinity software (version r20140717) using default parameters (Grabherr et al., 2011). For similarity search, the assembled transcripts were blasted against the NCBI non-redundant protein sequence database and TAIR database using Blast2GO with the e-value cutoff <10-10. RSEM version 1.2.15 software was used to estimate transcript abundance (Li & Dewey, 2011). The assembled sequences were analyzed for Gene Ontology (GO) and Kyoto Encyclopedia of Genes and Genomes (KEGG: Kanehisa & Goto, 2000) using Blast2GO. For differential gene expression analysis, Fastq files were aligned to the assembled transcriptome using TopHat2 alignment program (Kim et al., 2013). Transcriptome annotation file (GFF) was built using the Cufflinks program (Trapnell et al., 2010) by performing a combined assembly of four transcriptome datasets (FY, FO, MY, and MO). Transcript candidates for male and female were chosen using parameters as follows; male-highly represented transcripts [FPKM > 10 and > 0.5 for MY or MO and FPKM = 0 for both FY and FO] and [FPKM > 5 for both MY and MO and FPKM = 0 for both FY and FO] with length > 300 bp, and female-highly represented transcripts [FPKM > 10 and > 0.5 for FY or FO and FPKM = 0 for both MY and MO] and [FPKM > 5 for both FY and FO and FPKM = 0 for both MY and MO] with length > 300 bp. To identify shared transcripts among the four datasets, transcripts from each dataset with FPKM > 5 and length > 300 bp were analyzed using Venny version 2.1.0. Identified male and female specific transcripts were subjected to GO enrichment analysis using Fisher’s Exact Test with FDR cutoff = 0.01. Differentially expressed genes (DEGs) among the four transcript datasets were analyzed by Cuffdiff with FDR cutoff <0.05.

Extensive DNA fingerprinting analysis failed to identify any sex-linked marker for Asian Palmyra palm in Thailand

Previously, George et al. (2007) had developed a RAPD based male-specific marker (OPA-06₆₀₀) for the Asian Palmyra palm population in India. Initially, we tested this marker for sex identification in our population in Thailand using up to 20 male and 24 female individuals, but this marker was unable to confirm the sexes (Fig. S1). To identify sex-linked markers for Asian Palmyra palm in Thailand, we generated male and female DNA fingerprints using ten different DNA fingerprinting techniques as presented in Table 1. Although a number of potential sex-linked bands were obtained from SCoTs/EST-SSRs and SCoTs/TEs, after sequencing and re-testing these bands using specific primers, no sex-linked marker was obtained. Despite such extensive screening of DNA markers up to 1,204 primer pairs by the ten techniques, we did not obtain any sex-linked marker. This experiment showed that the DNA fingerprinting covered here is inadequate for identifying a sex-linked marker for Asian Palmyra palm. It also suggests that sex determination region in this species could be of small and very difficult to identify. Further attempts for this scheme in the Asian Palmyra palm should be aware of this limitation. Other means of sex identification for Asian Palmyra palm should be explored.

Identification of sex-related transcripts by SSH analysis using male and female inflorescence flowers

To identify genes related to sexes, we performed SSH using total RNA isolated from male and female inflorescences of Asian Palmyra palm. Because the floral development of this species is not well defined, we collected young inflorescence stems from male and female plants as soon as they emerged from the dense leaf sheets and isolated young floral tissues for RNA isolation. Female flower buds (∼2 cm in diameter) were removed from the inflorescence (Fig. 1G), while the male inflorescences (∼9 cm in length) were used as a whole (Fig. 1H). Direct cloning of subtracted-cDNA yielded 2,574 and 9,820 clones for male and female, respectively, and, after colony-PCR screening for > 500 bp inserted-fragments, we obtained 1,288 and 4,097 clones for male and female libraries, respectively (Table 2). These selected clones were re-tested against their opposite sex using two rounds of dot blot hybridization (I and II), resulting in 81 and 63 clones for male- and female-specific libraries, respectively. These clones were subsequently sequenced and searched in GenBank using BLASTX, and 60 male and 29 female clones were found matching to non-redundant genes in the plant database (Table S8). These sequences have been deposited in GenBank (JZ977504 –JZ977592) as ESTs for male or female inflorescence flowers of Asian Palmyra palm.

Among the total 99 identified clones, 91 and 98 clones share high similarities to sequences in the nuclear genome of date palm and oil palm, respectively. As oil palm has both male and female genome sequences available, we observed that all 99 sequences identified in Asian Palmyra palm are present in both male and female genomes of oil palm, suggesting that these sequences could not be used as sex-specific markers. Nonetheless, we tested 19 selected sequences on gDNA from male and female plants by PCR using specific primers (Table S9), and these failed to identify the sexes. Although this experiment was unable to provide a sex-linked marker, the list of expressed genes during male- and female-floral development of Asian Palmyra palm could be of use for future study.

De novo transcriptome sequencing of male and female inflorescences

To further identify sex-related genes for sex identification, we performed de novo transcriptome sequencing using RNA from male and female inflorescences. Four cDNA libraries were constructed from two floral stages of male and female (FY-female young inflorescences, FO-female old inflorescences, MY-male young inflorescences and MO-male old inflorescences; Figs. 1I–1J), which were in earlier stages than those used in the SSH experiment. From Illumina HiSeq2000 sequencing, we obtained 47,194,682-90,305,610 reads for each sample with an average length of 98 bp, after trimming the adapter sequences and removing low-quality nucleotides (<Q20) and short sequences (<25 nt) (Fig. 2). Sequence assembly using Trinity yielded 187,083 transcripts with 705 bp average length. Most of the assembled transcripts were between 200 and 300 bp in length, and up to 70,785 transcripts were > 500 bp in length (Fig. 2B). The transcripts were annotated by using BLASTX searches against the NCBI non-redundant protein database, and 77,578 transcripts (41.47% of initial transcripts) were identified as unique sequences with significant similarities (E <1e−10) to known protein sequences from 5,331 different species. The average alignment length (%) matched was 81.3% with the highest positive matched per alignment length being 90%, and the average percent identity was 81.24%. Most of these sequences were identified as similar sequences to those found in date palm (53%) and oil palm (37%) (Fig. 2C). The Transcriptome Shotgun Assembly are deposited at DDBJ/ENA/GenBank under the accession GFYQ00000000.

GO classification and pathway assignment by KEGG

Gene ontology (GO) terms of the 77,578 annotated transcripts were assigned using Blast2GO program in three categories: biological process, cellular component and molecular function. The transcripts were assigned into 66 functional groups, and top GO terms with more than 1% assigned transcripts in each category are presented in Fig. S2. Binding and catalytic activity were dominant in the molecular function category, while the integral component of the membrane and nucleus dominated the cellular component category. For the biological process, oxidation–reduction process and protein phosphorylation were the most represented groups. Subsequently, function classification and pathway assignments based on Kyoto Encyclopedia of Genes and Genomes (KEGG) showed that, among the 77,578 annotated transcripts, 16,635 were annotated with enzyme code EC numbers and mapped into 139 KEGG pathways. Pathways with more than 1% matched transcripts are presented in Fig. S3. Purine (map00230) and Thymine (map00730) metabolisms were the most matched pathways with 4,913 transcripts (18.89%) and 2,581 transcripts (9.92%), followed by Biosynthesis of antibiotics (map01130) with 1,582 transcripts (6.08%). Interestingly, starch and sucrose metabolism (map00500) presented at the fourth rank with 1,187 transcripts (4.56%). Transcripts mapped into this pathway were mostly related to sugar metabolism for fructose and sucrose production, but less supported to starch biosynthesis (Fig. 3 and Table 3; see the transcript IDs in Table S10). Other related sugar metabolic pathways were also found among the list of top pathways including 1.54% of glycolysis/gluconeogenesis (map00010), 1.25% of pentose and glucuronate interconversions (map00040), 1.19% of Galactose metabolism (map00052), 1.10% of fructose and mannose metabolism (map00051), 0.87% of pentose phosphate pathway (map00030) and 0.85% of inositol phosphate metabolism (map00562). This observation coincides with the facts that both male and female inflorescences of Asian Palmyra palm produce sweet sap, which has been used for making palm sugar for centuries.

Differential expression of genes between male and female inflorescences

Among the initial 187,083 transcripts, we observed a number of transcripts that were highly represented in either male or female datasets, but none in their opposite sex (FPKM = 0); 33 and 11 transcripts were identified from female and male datasets, respectively (length > 300 bp, FPKM > 5 for both FY and FO or MY and MO, and FPKM > 10 and > 0.5 for FY or FO and MY or MO) (Table S11). Although annotations of these transcripts did not show any evidence related to genes for male- or female-specific development, we observed four cell wall-related transcripts in the female datasets, and this may reflect that the developing female flower undergoes rapid and extensive organ enlargement, whereas the male flower is limited to a small size. Because the genome sequence of Asian Palmyra palm is currently unavailable, we thus tested whether these transcripts could be used for sex identification by PCR using male and female gDNA and primers specific to these 44 transcript sequences (Table S12). However, these primers gave similar band patterns between male and female gDNA (Fig. S4), indicating that these primers cannot be used for identifying the sexes.

By comparing the transcripts among the four datasets (length >300 bp and FPKM > 5), we found that 17,231 transcripts were shared among all datasets, and 4,514 (14.4%) and 3,312 (10.5%) transcripts were identified as male- and female-specific transcripts, respectively (Fig. 4 and Table S13). These transcripts were further classified into specific MY (2,192 transcripts), MO (1,405 transcripts), FY (1,355 transcripts) and FO (1,165 transcripts) to identify transcripts that may relate to male or female floral development stages. Subsequently, we analyzed enriched GO terms for the male- and female-specific datasets (length > 300 bp and FPKM > 5), and top enriched GO terms (FDR <1E−02) are presented in Table 4 (see Table S14 for transcript IDs). All GO terms observed here were over-represented compared to the reference sets. Interestingly, carbohydrate metabolism and cell wall-related processes were much apparent in the female-specific transcripts, while various catabolic processes for biological compounds dominated the male-specific transcripts.

In light of this transcriptome analysis, we cross-referenced the 60 male and 29 female-specific clones from the SSH experiment to the transcript abundance data. Noting that RNA samples used in the SSH experiment were obtained from an older inflorescence stage than those used for transcriptome analysis. The transcript IDs were readily identified with more than 90% identical matches and > 300 transcript length (Table S15). However, we found that, based on FPKM values, the sex-specific clones were indeed uncorrelated to almost all of the transcript data, and only F152 (predicted proline-rich protein 4-like) clone could be identified for their expression towards the female. Though, this clone has no direct relationship to sex development based on the annotation.

To further verify sex-related genes, we analyzed differentially expressed genes among the four datasets by using Cuffdiff with FDR <0.05 cutoff. Initially, 816 transcripts were identified, but only 43 transcripts displayed differential expression between sexes with transcript length > 300 bp, FPKM > 5, GO terms and significant q value (<0.05) (Table 5). Among these 43 transcripts, seven transcripts were annotated with genes previously identified to be involved in sex determination and flower development: two and five transcripts for female and male datasets, respectively. Furthermore, we observed six and one transcripts encoding transcription factors that were highly expressed in female and male datasets, respectively. Although being identified for differential expression between the sexes, c1819_g1_i1 and c142400_g1_i1 transcripts encoding ethylene-responsive transcription factors were highly expressed throughout the four datasets, and these genes may be required for the floral development. The list of gene candidates indicated here could be used for a further study on sex determination and floral development in Asian Palmyra palm and other related palm species.
