Unveiling the impact of organically activated biochar on physiological, biochemical, and yield attributes of maize under varied field moisture conditions

Preparation, activation and amendment of biochar in soil

Biochar production was undertaken in 2022 by utilizing raw material sourced from the gum Arabica tree (Acacia nilotica) at the University of Agriculture, Faisalabad. Following a drying phase, acacia shavings were subjected to pyrolysis at a temperature of 450 °C for a duration of 3 h. For the preparation of vermicompost, corn stover was employed as the raw material, and the red earthworm species Eisenia fetida was employed for the vermicomposting process. Biochar was activated according to the procedure of Jahan et al. (2023). Three concentrations 0 tonnes ac⁻¹, 2 tonnes ac⁻¹ and 4 tonnes ac⁻¹ of activated biochar was amended by thorough mixing in the top 15 cm of soil. The experimental layout was consisted of split-split-plot design. After three month of amending activated biochar in the field soil sample were acquired for physicochemical testing.

Soil analysis

Three soil samples were taken from from the top 0–20 cm layer from each treatment and a representative sample was attained by thorough mixing of sub-samples. After heating in an oven at 80 °C for 24 h, the samples were ground and sieved for further testing. The loamy sand texture of the soil was ascertained by the Brady (1990) procedure. The estimation of pH values was made by following the standard procedure ISO 10390. The electrical conductivity of the soil was calculated by the method given by Rayment & Higginson (1992). Soil organic matter, oxidizable organic carbon, total organic carbon was determined by the method of George et al. (2017). While, soil phosphorus was determined by the procedure of Olsen & Sommers (1982). Soil potassium was determined by flame photometer.

Field experiment

The field experiment was conducted at location 32°38.37′N, 74°9.00′E (Gujrat) for exploring the suitable level of activated biochar under three moisture regimes (100% ET_C, 70% ET_C, and 50% ET_C). The field was chosen on account of its low water holding capacity (18% FC) due to loamy sand soil and arid climatic conditions. The following seeds of maize hybrids was used DK-9108, DK-6321 and Sarhaab.

The experiment was placed out in a split-split-plot design with three replications. Healthy seed of three maize varieties were sown in subplots on 19th February, 2023. There were 27 treatments with three replicates. The area of each treatment plot was 16 m²; width = 2 m and length = 5.33 m, each having 3 rows with 0.3-meter row spacing. The following treatments were applied: T1 = DK-9108 + 0 tonnes ac⁻¹ AB + 100% irrigation water (IW) of FC, T2 = DK-9108 + 0 tonnes ac⁻¹ AB + 70% IW, T3 = DK-9108 + 0 tonnes ac⁻¹ AB + 50% IW, T4 = DK-9108 + 2 tonnes ac⁻¹ AB + 100% IW, T5 = DK-9108 + 2 tonnes ac⁻¹ AB + 70% IW, T6 = DK-9108 + 2 tonnes ac⁻¹ AB + 50% IW, T7 = DK-9108 + 4 tonnes ac⁻¹ AB + 100% IW, T8 = DK-9108 + 4 tonnes ac⁻¹ AB + 70% IW, T9 = DK-9108 + 4 tonnes ac⁻¹ AB + 50% IW, T10 = DK-6321 + 0 tonnes ac⁻¹ AB + 100% IW, T11 = DK-6321 + 0 tonnes ac⁻¹ AB + 70% IW, T12 = DK-6321 + 0 tonnes ac⁻¹ AB + 50% IW, T13 = DK-6321 + 2 tonnes ac⁻¹ AB + 100% IW, T14 = DK-6321+ 2 tonnes ac⁻¹ AB + 70% IW, T15 = DK-6321 + 2 tonnes ac⁻¹ AB + 50% IW, T16 = DK-6321 + 4 tonnes ac⁻¹ AB + 100% IW, T17 = DK-6321 + 4 tonnes ac⁻¹ AB + 70% IW, T18 = DK-6321 + 4 tonnes ac⁻¹ AB + 50% IW, T19 = Sarhaab + 0 tonnes ac⁻¹ AB + 100% IW, T20 = Sarhaab + 0 tonnes ac⁻¹ AB + 70% IW, T21 = Sarhaab + 0 tonnes ac⁻¹ AB + 50% IW, T22 = Sarhaab + 2 tonnes ac⁻¹ AB + 100% IW, T23 = Sarhaab + 2 tonnes ac⁻¹ AB + 70% IW, T24 = Sarhaab + 2 tonnes ac⁻¹ AB + 50% IW, T25 = Sarhaab + 4 tonnes ac⁻¹ AB + 100% IW, T26 = Sarhaab + 4 tonnes ac⁻¹ AB + 70% IW, T27 = Sarhaab + 4 tonnes ac⁻¹ AB + 50% IW.

Soil moisture was maintained by Eq. (1) (Faghih et al., 2021). (1)${\displaystyle I=ETc=\left(\theta \mathrm{fc}-\theta \mathrm{i}\right)DR}$

where, “I” represents the total of irrigation water (mm), “θfc” indicates volumetric moisture content at field capacity and “θi” represents the soil moisture content before irrigation. While, “DR” indicates the root depth.

The volumetric moisture content at field capacity of soil before (θfc) and after (θi) irrigation was monitored by soil moisture meter PMS-714. The field capacity of the soil was determined by assessing the moisture content 72 h after fully saturating the soil while covered from the top to avoid evaporation.

Plant sampling and analysis

For estimation of physiological and biochemical attributes of maize under different treatments, fresh leaves were sampled at V14 (collar of 14th leaf become visible) stage and R3 (milking stage) on 9th April, 2023 and 19th May, 2023, respectively. The leaf relative water content was calculated by applying the Eq. (2) according to Weatherley’s (1950) method. (2)${\displaystyle Leafrelativewatercontent=\frac{Freshweight-Dryweight}{Saturatedweight-Dryweight}\times 100.}$

The chlorophyll and carotenoid pigment profiling of maize leaves was done by the method of Arnon (1949) and Lichtenthaler & Wellburn (1983), respectively. Crushing of leaf sample (0.1 g) was done with 5 mL of 80% acetone. The solution was centrifuged (15,000×g for 5 min) and the upper layer was transferred to the clean cuvette of the spectrophotometer (UV-Vis; Shmadzu 35, RP China) and absorbance was recorded at 663-nm, 645-nm and 470-nm.

Leaf sugar contents were estimated by crushing 0.5 g leaf material in clean mortar with (10 mL) distilled water (DuBois et al., 1956). In a clean test tube 0.1 mL of filtrate with 1 mL of phenol (5% v/v) was added. After the incubation at room-temperature for 60 min, 5 mL of concentrated H₂SO₄ was added in the test tube. The same procedure was repeated for the blank and filtrate from other treatments. The absorbance value of the sample and blank was noted at 420 nm by using spectrophotometer.

The leaf proline content was determined by the method of Bates, Waldren & Teare (1973). By following this procedure, pre-chilled dry leaf 0.1 g was ground in a mortar after that homogenized it with 4 mL sulfosalicylic acid (3%). This mixture was kept at 5 °C for 24 h. Then the extract was centrifuged at 3000 rpm for 5 min. Acetic ninhydrin reagent (4 mL) was mixed with supernatant and after properly shaking the mixture; the test tube was placed for one hour at 100 °C in the water-bath. After cooling the extract toluene (4 mL) was added in it. The absorbance of the toluene layer was analyzed at 520-nm in a spectrophotometer.

The FT-IR spectra of powdered leaf samples were obtained using the KBr (potassium bromide) method, utilizing a Nicolet iS5 Thermo Scientific instrument (USA), following the procedure outlined by Celi, Schnitzer & Nègre (1997). The infra-red spectra of the leaf samples were obtained in the range of 4000 to 500 cm⁻¹. Further processing and analysis of the spectra were conducted using Origin Pro 2020.

Plants were collected at maturity in triplicates for absolute growth analysis. Shoot, leaves and roots of the plants were dissected properly and their fresh weight was calculated in gram by using the digital electronic balance. After that, roots, stems and leaves were placed on the chart and scanned. Further processing on the scanned images was done by Image J software (NHIV, v. 1.51 64-bit, Bethesda, MD, USA) and the length of stem, root and leaf area was measured. The counting of number of leaves per plant was done manually. The dry weights of the stem, roots and leaves were recorded after oven drying the sample for 72 h at 70 °C. At maturity following yield attributes were determined; ear length (cm), 1,000 grain weight, number of grains rows per ear, grain weight per ear.

Statistical analysis of data

The MINITAB 19 software was used to apply the general linear model (GLM) for univariate analysis. The significance of the treatment was determined using the Tukey’s least significant difference (LSD) test at a 95% confidence level. The chord diagram of soil physio-chemical attributes and heatmap of plant growth parameters were made by using R software (R−4.3.1-x86 64.pkg).

Soil analysis

The interaction between levels of AB amendment (0, 2, and 4 tonnes acre⁻¹) and soil physicochemical properties is presented in the form of a chord diagram (Fig. 1). The chord diagram shows the relation between AB amendment level (at the base of the circle) and associated soil characteristics (pH, electrical conductivity (EC), organic matter, available phosphorus, available potassium, organic carbon, and oxidizable organic carbon). Each chord connecting an AB amendment level to soil characteristics, i.e., EC, pH, and organic matter, highlights the strength of association, with thicker chords indicating stronger association. The chord diagram indicates a strong association between soil amended with AB at rates of 2 and 4 tonnes acre⁻¹ and the EC, which was significantly (P < 0.05) higher at 4.4% and 7.3%, respectively, than that of soil not amended with AB. In contrast to soil without AB amendment, 4 tonnes acre⁻¹ biochar-amended soil exhibited a significant decrease (4.34%) in pH (P < 0.05). The application of 2- and 4-tonnes acre⁻¹ organically activated biochar resulted in a substantial (P < 0.05) increase of 7.14% and 16.6% in soil organic matter respectively. Findings showed that adding 2 and 4 tonnes of AB to the soil improved the available phosphorous and potassium by 9.72 to 11.43% and 9.96 to 29.27%, respectively. Additionally, soil total organic carbon increased, showing a significant difference of 8.33% at the 2 tonnes acre⁻¹ amendment level and 16.6% at the 4 tonnes acre⁻¹ amendment level. Similarly, organically activated biochar amendment at 2 and 4 tonnes acre⁻¹ significantly enhanced oxidizable carbon content in soil by 7.18% and 17.68%, respectively, compared to non-amended soil.

Physiological and biochemical analysis

Leaf FTIR

The leaf FTIR spectra of three verities are presented in Fig. 2. The peak at 3700–3000 cm⁻¹ signifies the stretching of phenolics’ OH groups. When compared to 100% IW, the peak intensity of phenolics in DK-9108 decreased by 7%–9% at 70% and 50% IW in soil without AB amendment. However, with a 2 tonnes acre⁻¹ AB amendment in soil, the peak intensity of phenolics was slightly increased by 1.5% and 2.4% under 70% and 50% IW than 100% IW. In DK-6321, the peak intensity of phenolics increased by 2.5–7% in 4 tonnes acre⁻¹ AB amended soil under 70%–50% IW, as compared to plants grown in soil without AB amendment. The minor peak at 2,900 cm⁻¹ is caused by stretching vibration of C =O from alkanes, and its lowest intensity was seen in DK-9108 under 100% IW without AB amendment in the soil. The intensity of alkanes increased by 17–80% in DK-6321 plants grown in soil amended with 4 tonnes acre⁻¹ AB under 70%–50% IW. The peaks at 1,700 cm⁻¹ show the stretching vibration of C =O from alkyl esters and pectin. The peak strength increased by 66% and 93% in DK-6321 plants in 2 and 4 tonnes acre⁻¹ of AB amended soil under 70% IW. The 1,644 cm⁻¹, 1,384 cm⁻¹, and 1,247 cm⁻¹ peaks show the C-N stretching vibration of amide I, amide II, and amide III, respectively. A decrease in the level of irrigation water in DK-9108, DK-6321, and Sarhaab results in an increase in the peak intensities of amides. The peak at 1,000–1,100 cm⁻¹ represents the stretching vibration of the C-O, C-H, and C − O − C from carbohydrates. Compared to plants cultivated in soil without an AB amendment, the peak intensity of carbohydrates increased under 50% IW in 2 and 4 tonnes acre⁻¹ AB amended soil, with plants of 4 tonnes acre⁻¹ showing a 43% greater intensity. In DK-6321, under 100%, 70%, and 50% of IW, the peak intensity of carbohydrates rose in both levels of AB amended soil.

Morphological growth attributes

The results pertaining to maize plant morphological attributes, derived from a three-way analysis of variance (ANOVA), are detailed in Table 3. The maize plant in AB amended soil exhibited longer roots and shoots. The DK-6321 cultivated in a 4-tonnes acre⁻¹ AB amendment level showed enhanced root length (48.85%–54.14%) and shoot length (10.21%–99%) under 50%–70% IW compared to DK-6321 grown in soil without AB amendment. In soil without AB amendment, when compared to Sarhaab grown under 100% IW, a significant reduction in root length (5.27%) and shoot length (2%) was seen under 50% IW. The DK-6321 plants exhibited significantly higher root fresh weight (39.40%–43.07%) and shoot fresh weight (5%–6.5%) in soil treated with 4-tonnes acre⁻¹ of AB amendment under 50%–70% IW, compared to the DK-6321 grown in soil without AB amendment under 50%–70% IW. When compared to Sarhaab grown in soil without AB amendment under 100% IW, shoot and root fresh weight decreased significantly (1.5%–5.9%) under 50% IW. In 4-tonnes acre⁻¹ AB amended soil 45.54%–48.87% increased leaf fresh weight was recorded in DK-6321 under 70%–50% IW when compared with DK-6321 in soil without AB amendment under 70%–50% IW. The lowest leaf fresh weight was recorded in Sarhaab (10.2%) grown in soil without AB amendment under 50% IW, in contrast to Sarhaab under 100% IW. In DK-6321 plants cultivated in 4-tonnes acre⁻¹ AB amended soil with 50–70% IW had a higher root dry weight (45.5%–84.9%) and shoot dry weight (26.04%–25%) compared to DK-6321 in soil without AB amendment under the same IW. The root dry weight and shoot dry weight of Sarhaab cultivated without AB amendment in soil under 50% IW decreased by 20.75% and 79%, respectively, compared to 100% IW.

Yield attributes

The results of the three-way analysis of variance (ANOVA) for maize plant yield characteristics are delineated in Fig. 3. All maize hybrids underwent a reduction in ear length due to water stress; DK–9108 under 50% IW and soil without AB amendment had the lowest ear length (54.14%) compared to DK-9108 under 100% IW. The DK-6321 had significantly longer ear length (9.89%–29.48%) when grown in 4-tonnes acre⁻¹ AB amended soil under 50%–70% IW compared to plants cultivated in soil without AB amendment. At 70%–50% IW, DK-6321 showed increased ear weight (164.9%–172.8%) in 4-tonnes acre⁻¹ AB amended soil compared to DK-6321 grown in soil without AB amended soil. A significant decline of 8.62% was observed in soil without AB amendment in DK-9108 under 50% IW when compared with DK-9108 under 100% IW. The total number of seeds per ear was recorded to be highest (31.29%) in DK-6321 under 70% IW in 4-tonnes acre⁻¹ AB amended soil by 31.29% as compared with DK-6321 under 70% IW in non-amended soil. The result showed a 157%–162.64% increase in 1,000-grain weight in DK-6321 under 70%–50% IW in soil amended with 4-tonnes acre⁻¹ when compared with DK-6321 in soil without AB amendment. In contrast to Sarhaab grown in soil without AB amendment under 100% IW, there was a 26.5% decrease in 1,000-grain weight under 50% IW.

Multivariate analysis

The heatmap (Fig. 4) illustrates the response of three maize varieties, DK-6321, DK-9108, and Sarhaab, to different levels of activated biochar (0-tonnes acre⁻¹ AB, 2-tonnes acre⁻¹ AB, and 4-tonnes acre⁻¹ AB) under varying irrigation regimes (100%, 70%, and 50% of ETc). Each row represents a combination of specific maize varieties, biochar amendments, and irrigation levels, while each column represents the physio-biochemical and yield attributes of maize. The color intensity within each cell indicates the performance of the respective maize variety under the specified treatment conditions, with darker red shades representing higher performance and darker blue shades representing lower performance. The highest improvement in photosynthetic pigments, relative water content, morphological parameters, and yield parameters is shown by DK-6321 under 100%, 70%, and 50% irrigation of ETc, with 4-tonnes acre⁻¹ levels of activated biochar, as evidenced by the darker shading in the corresponding cells. Conversely, Sarhaab showed optimal performance at lower levels of activated biochar under 50% irrigation of ETc, as indicated by the light blue shading in the respective cells.

Physicochemical properties of soil

The AB amendment improved the soil organic carbon and organic matter content but also caused a slight increase in electrical conductivity that might be due to the higher nutrient and organic carbon content of biochar (Joseph et al., 2020; Qi et al., 2020). Moreover, AB can stimulate the polymerization of small organic particles via a surface catalytic reaction; therefore, macropores of biochar may absorb small organic molecules from the soil (Zhang, Wang & Feng, 2021). In the current study, it was observed that the pH of AB amended soil was slightly acidic. This decline in soil pH was most likely caused by the oxidation of biochar and production of acids, facilitated by organic matter in the soil (Premalatha et al., 2023). Simultaneously, biochar also caused the oxidation of organic matter, resulting in the formation of humic acid and other organic acids (Mittal et al., 2023). This process may have caused a minor pH reduction in soil (Huang et al., 2019a). At present, it was also observed that the AB amended soil had the highest potassium and phosphorus content in contrast to the non-amended soil. This can be due to the highest potassium and phosphorus content of wood biochar, which becomes readily available to plants after dissolving in soil water (Jindo et al., 2020). Increased K absorption is crucial for maintaining guard cell pressure, which controls stomatal conductance, and for achieving optimal osmoregulation (Brantley et al., 2016). In order to improve soil fertility, the organic content of vermicompost enhances the process of nutrient cycling and mineralization controlled by the soil microbial population (Igalavithana et al., 2017). The AB amendment enhances soil characteristics such as enhanced WHC, slightly acidic pH, reduced nutrient leaching, delivers critical nutrients to the soil on its own, and protects crops from water stress (Yang et al., 2018; Fahad et al., 2022). In fact, activated biochar is a helpful organic soil supplement that raises the soil’s fertility. Both chemical and organic activation of biochar can improve the surface area and water retention capacity of soil, but organic activation of biochar is preferred due to its safer impact on the agroecological system (Ghassemi-Golezani & Farhangi-Abriz, 2022; Jahan et al., 2023). Mohamed et al. (2016) reported that 2% chemically engineered biochar caused an increase in water holding capacity of loamy sand soil by 30% after an incubation period of six weeks, while Jahan et al. (2023) reported an increase in water holding capacity of 31% to 41% in 2.5% and 5% organically activated biochar amended loamy sand soil after a period of 20 weeks.

Physiological and biochemical attributes

To cope with drought, plants evolved a variety of morphological, biochemical, and physiological adaptations, as changes in shoot-to-root ratio, leaf area, accumulation of various osmolytes (proline and soluble sugars), membrane stability, photosynthetic pigments, and relative water content (Farooq et al., 2024; Shirvani et al., 2024). By holding the right amount of moisture in its tiny micropores and making it available to plants during the drought, biochar supplementation enhanced the growth qualities of crops under water scarce conditions (Le Guyader et al., 2024).

The chlorophyll a and b content and total chlorophyll and carotenoid content were significantly reduced at 50% IW in all maize hybrids, and the highest decline was noted in Sarhaab at 50% IW (indicating the sensitivity of Sarhaab to water stress). This reduction might be due to overproduction of the reactive oxidative species (Jahan et al., 2023). These ROS triggered photo-oxidation and, hence, degradation of the ultrastructure of the thylakoid membrane and photosystems, reducing the swelling of stromal lamella, which ultimately destroys the thylakoid and antenna complexes (Huang et al., 2019). These alterations were responsible for the overall decline in photosynthetic pigments due to the loss of PS II and light harvesting complexes (Rehman et al., 2023). However, with the addition of AB amendment to the soil, an improvement in chlorophyll a and b content in the maize hybrids (DK-9108, DK0-6321, and Sarhaab) was detected even at 50% IW. The highest chlorophyll a and b content was recorded in DK-9108 at both the V14th and R3 stages, which might be an indication of the harmony of this maize hybrid with the AB amendment in the soil. The diverse pore range of the AB has the ability to retain moisture for a longer duration and make it available for plants under water-scarce conditions (Ansari et al., 2020). So, this gradual supply of moisture to the maize plant prevents the thylakoid membrane from shrinking and improves photosynthetic pigments, particularly in DK-9108, even under drought stress (Ahmad et al., 2021; Jafari, Garmdareh & Azadegan, 2019; Tayyab et al., 2018).

The proline content was enhanced as the severity of water stress increased in the leaves of all maize hybrids grown in soil without AB amendment, and the highest proline content was detected in Sarhaab. Proline is a stress indicator and acts like a compatible osmolyte, which tends to maintain the internal cellular organisation under stress conditions. It is also very important for keeping plant cell membranes healthy by getting rid of extra reactive oxygen species and keeping plant cell redox reactions safe (Ahmed et al., 2018). However, in 2-4-tonnes acre⁻¹ AB amended soil at both V14th and R3 growth stages, low proline content in the leaves of the maize hybrid was noted even under 50%–70% IW. This reduction in proline content, along with an enhancement in photosynthetic pigments, further justified the adequate moisture provision potential of biochar to plant roots even under deficit irrigation, which consequently helps the maize plants maintain normal redox balance even under water stress conditions (Mannan et al., 2017).

When maize plants were cultivated without an AB amendment in the soil during the V14th and R3 stages, Sarhaab showed the maximum sugar content under 50% IW. Similarly, DK-9108 and DK-6321 also showed increased sugar content. This could be because the breakdown of carbohydrates stabilises the proper cellular osmotic potential, maintaining optimal water uptake into cells to achieve maximum turgidity (Du et al., 2020; Thalmann & Santelia, 2017). On the contrary, plants cultivated in soil supplemented with biochar exhibited a low sugar content. This might be the result of AB facilitating increased moisture availability (Yadav et al., 2018). The low sugar accumulation in all maize hybrids at both AB amendment levels (2-tonnes acre⁻¹ and 4-tonnes acre⁻¹), particularly under 70% and 50% IW in AB amended soil, is evidence that the plants were able to withstand water stress conditions.

All three maize hybrids had lower relative water content because, under water stress, plants closed their stomata to reduce transpiration. However, it also influences water conductance from roots to leaves, lowering leaf water content (Luo et al., 2020). Relative water content is an essential measure of plant water status (Bistgani et al., 2017). Maize hybrids grown on AB-amended soil (2-4 acres) showed higher relative water content in the leaves of DK-9108, DK-6321, and Sarhaab. The AB integrated recalcitrant carbon content with high porosity, which improves soil’s water retention efficacy by releasing moisture to roots and improving relative water content in plants under water stress circumstances (Jahan et al., 2022; Ullah et al., 2020).

Drought and plant metabolites

The FTIR analysis of plants is the most convenient approach for the identification of different inorganic and organic compounds present in them. After screening, phenolic, alkane, alkyl-esters, pectin, amides (I-II-III), proteins, and carbohydrates functional groups were found. Phenolic compounds usually contain OH groups and are produced in plants during water stress conditions. All maize plants grown in soil without AB amendment showed the highest peak intensity of phenolics under water stress (70%–50% IW). Basically, water stress stimulates ROS production in plants; however, to protect themselves from oxidative damage, plants synthesise various secondary metabolites, and phenolics are one of them (Stiller et al., 2021; Baliyan et al., 2022). Phenolics are non-enzymatic antioxidants that are associated with scavenging free radicals (Hasanuzzaman et al., 2021; Zulfiqar et al., 2023). As the intensity of water stress increases, the biosynthesis of phenolic compounds also enhances (Parveen et al., 2019). While the phenolic peaks were detected to be less intense in DK-9108, DK-6321, and Sarhaab in soil with 2-4 tonne acre⁻¹ AB amendment levels, even at 50% and 70%, this might be due to the appropriate moisture and nutrient provision to plants by highly porous, spongy biochar. The moisture and nutrients are supplied to the plants gradually to withstand water stress intervals. So, maize hybrids cultivated under AB amended soil reduced the phenolic content due to less production of ROS (Gharred et al., 2022).

The band intensities at 2,900 cm⁻¹, 1,850–1,250 cm⁻¹, and 1,000–900 cm⁻¹ suggest alkanes, alkyl ester, amides, polysaccharides, and proteins (Lalay et al., 2024). Currently, all hybrid maize varieties show a decrease in peak intensities at 70%–50% IW in soils without AB amendment. A reduction in peak intensities of amides, proteins and polysaccharides under stress was also reported by Ogbaga et al. (2017). Water stress destroyed protein content and slowed down the production of chlorophyll. This led to a huge drop in photosynthesis, which in turn decreased the leaf’s carbohydrate content (Mahmoud et al., 2022). While higher peak intensities were observed in the DK-9108, DK-6321, and Sarhaab grown in AB amended soil under all IW levels. The alkane and alkyl ester content was increased in the plants grown in AB amended soil, which makes them more resistant to water stress by synthesizing wax layers. Increased alkane chain lengths of C29 and C31 improved drought resistance (Li et al., 2020). Water permeability from cuticular wax is not dependent on its overall covering, but rather on its composition, particularly on the nonpolar component (mostly alkanes), which functions as a very effective water barrier (Tunstad et al., 2024). Pectin is the primary component of the cell wall and aids in cell growth. Plant cell walls protect against drought stress because of a trait that is dependent on several of its fundamental constituents, one of which is pectin. Our FTIR data revealed an increase in pectin concentration in maize plant leaves grown in AB amended soil, making them more resistant to water stress and aiding in the maintenance of optimal cell size and shape for normal cell communication and function (Forand et al., 2022; Shin et al., 2021). The increased protein and carbohydrate content of plants grown in AB-amended soil demonstrated that AB, by offering the highest possible level of hydration, mitigated the negative effects of water stress on carbon absorption and photosynthetic capacity (Wang et al., 2021). The AB provides plants with an abundance of carbon and nitrogen, which facilitates the production of chlorophyll, sucrose, and protein. As a result, the leaves ultimately exhibited an increase in carbohydrate and amide concentrations (Gharred et al., 2022; Khan et al., 2021; Singh et al., 2019).

Morphological and yield attributes of plants

Water stress significantly reduced the fresh and dry weights of root, shoot, and leaf in all maize hybrids (DK-9108, DK-6321, and Sarhaab), with Sarhaab showing the greatest loss at 50% IW in soil. The possible cause for this phenomenon could be a reduction in cell turgidity resulting from a diminished water potential across maize plant cells, which subsequently leads to the contraction of cell walls and impedes cell division (Carvalho et al., 2021; Shakeel et al., 2022). Moreover, the collapse of organelles (chloroplasts, mitochondria) in flaccid cells resulted in a decrease in photosynthesis, which eventually lowered plant biomass (Endres et al., 2019; Keipp et al., 2020). Water stress induces a reduction in plant growth via a variety of mechanisms, including osmotic adjustment, hydraulic status, phytohormones, and ROS signals (Moreno-Galván et al., 2020). These ROS are extremely toxic to plant cells and can oxidise essential cellular components such as nucleic acids, fats, and proteins, promoting lipid peroxidation, protein denaturation, and DNA mutations, resulting in pigment complex degradation, cell death, and reduced plant biomass (Huang et al., 2019). While fresh and dried weights of DK-9108, DK-6321, and Sarhaab were enhanced in AB-amended soil, the greatest increase was observed in DK-6321 at four tonnes acre⁻¹ AB, even at 50% and 70% IW. The AB amendment acts as a water bank, protecting the plat cell membrane from oxidative damage at the permanent wilting point by gradually providing moisture and nutrients to maintain normal water potential and achieve cell turgidity for maximum transpiration, photosynthesis, and stomatal conductance (Bu et al., 2020; Hafeez et al., 2017; Tayyab et al., 2018). Adding AB to soil increased carbon storage, nutrient retention, and water uptake around roots, which led to better plant growth in water-stressed situations (Romdhane et al., 2019; Safari et al., 2023).

The length of the shoots and roots decreased under water stress in all maize hybrids, particularly in Sarhaab, in soil that did not include any AB amendment. The reduction in water availability hindered the cell elongation mechanism, which was responsible for the root and shoot length decline. Water stress arrests the flow of sugars from the leaves to the growing regions of roots and shoots. It also stopped cells in the roots and shoots from stretching (Khan et al., 2019). Severe water stress affected soil characteristics and nutrient transfer from soil to plants, resulting in decreased root and shoot length due to a nutrient deficit even in fertilised soil (Bista et al., 2018; Seleiman et al., 2021). However, soil amendment with AB resulted in increased root and branch length in Sarhaab, DK-9108, and DK-6321. AB boosted soil moisture and critical nutrients, improving soil fertility and making it available to maize plants (Murtaza et al., 2021). The nutrients and moisture stored by AB help plants control their metabolic activity during drought stress (Bitarafan, Liu & Andreasen, 2020; Ali et al., 2021). The present research outcomes, which indicate elevated levels of photosynthetic pigments and enhanced relative water content, may additionally be associated with elongated roots and shoots in plants experiencing water scarcity.

In all maize hybrids, yield parameters such as ear length, ear weight, total number of grains per ear, and 1,000 grain weight were significantly reduced at 50% IW in soil without AB amendment, with the biggest decline observed in Sarhaab (most drought sensitive). Water stress alters plant yield metrics (Bodner, Nakhforoosh & Kaul, 2015). Water stress during grain filling in maize may result in reduced ear weight and length, total number of seeds per ear, and weight per thousand grains (Elshamarka et al., 2024). Water stress reduces yield parameters by reducing photosynthesis (due to reduced photosynthetic pigments) and hindering flower and grain filling, resulting in fewer ear per plant, fewer grains per ear, and lower grain weight (Seleiman et al., 2021; Yousaf et al., 2022). All maize hybrids planted in soil amended with 2-tonnes acre⁻¹ and 4-tonnes acre⁻¹ showed higher ear length, ear weight, total number of grains per ear, and 1,000 grain weight; DK-6321 showed the largest increase in 4-tonnes acre⁻¹ soil even under 50%–70% IW. Because of their large surface area and pore volume, AB amendments improve the soil’s ability to retain water, allowing the soil to hold a suitable amount of plant-available water during times of stress (Niu et al., 2017; Singh, 2019). Hence, one of the best methods for lessening the detrimental effects of water stress on maize productivity is enhanced soil structure and water retention capacity via activated biochar.
