Identification of Cassiopea sp. in Lake Macquarie, Australia and revision of the taxonomic status of Cassiopea maremetens Gershwin, Zeidler & Davie, 2010 (Cnidaria: Scyphozoa: Cassiopeidae)

Introduction

Upside-down jellyfish (Cassiopea spp.) are unusual scyphozoans because they spend the majority of the medusa phase of their lifecycle resting on the benthos, with the bell facing downwards, and the oral arms directed upward into the water column (Ohdera et al., 2018). Cassiopea occurs world-wide in tropical to sub-tropical regions, in shallow and protected habitats, such as coral reefs, mangrove forests, seagrass beds, or even human-made environments (Ohdera et al., 2018; Rowe et al., 2022b; Stoner et al., 2014; Thé et al., 2020a). Some species of Cassiopea, however, are considered to have been artificially translocated, and in some cases becoming invasive (Bolton & Graham, 2006; Holland et al., 2004; Keable & Ahyong, 2016; Rowe et al., 2022b). This is especially the case for Cassiopea andromeda (native to the Red Sea), which has been recorded from shrimp farms in Brazil (Thé et al., 2020b), and the eastern Mediterranean Sea as a Lessepsian migrant where it is common on sandy bottom coves on the Aegean coast of Turkey (Gülşahin & Tarkan, 2012), and other harbours in the Mediterranean (Maggio et al., 2019). Range expansions can occur via localised dispersal, or through direct anthropogenic interventions including shipping, ballast water and release through the aquarium trade (Bolton & Graham, 2006; Graham & Bayha, 2008; Morandini et al., 2017). In some localities, Cassiopea has thrived and become invasive (Thé et al., 2020b). Characteristics considered important in their success as invaders include tolerance of a broad range of environmental parameters, ability to be mixotrophic, high reproductive rate and the ability to reproduce both sexually and asexually (Holland et al., 2004; Keable & Ahyong, 2016; Maggio et al., 2019; Mammone et al., 2023; Morandini et al., 2016; Schiariti et al., 2014; Thé et al., 2023). Additionally, Cassiopea can have reproductive blooms in high densities (Morandini et al., 2017; Stoner et al., 2014). Under increasingly favourable environmental conditions associated with human impacts, including coastal development and rising temperatures with climate change, these blooms may occur more frequently (Brotz & Pauly, 2016; Ohdera et al., 2018; Richardson et al., 2009; Rowe et al., 2022a; Stoner et al., 2014). High densities of Cassiopea can lead to competition with other benthic fauna for light, space and food, and smothering of seagrass and other aquatic vegetation (Stoner et al., 2011).

Cassiopea is the only genus in the family Cassiopeidae. The most recent synopses of the genus recognised 12 valid species (Collins, Jarms & Morandini, 2025; Jarms et al., 2019): 1, C. andromeda (Forskål, 1775); 2, C. culionensis Light, 1914; 3, C. depressa Haeckel, 1880; 4, C. frondosa (Pallas, 1774); 5, C. maremetens Gershwin, Zeidler & Davie, 2010; 6, C. mayeri Gamero-Mora et al., 2022; 7, C. medusa Light, 1914; 8, C. mertensi (Brandt, 1838); 9, C. ndrosia Agassiz & Mayer, 1899; 10, C. ornata Haeckel, 1880; 11, C. vanderhorsti Stiasny, 1924; and 12, C. xamachana Bigelow, 1892. However, species of the genus can be extremely difficult to distinguish based on morphological characters alone because of their conservative morphology, with few known reliable morphological taxonomic characters (Gamero-Mora et al., 2022; Holland et al., 2004). Such a situation is commonplace in scyphozoan systematics, which has traditionally based descriptions on morphological characters that have to be interpreted from soft structures whose form is often susceptible to the vagaries and differences in preservation leading to possibly premature assertions of high morphological plasticity (Arai et al., 2017; Gohar & Eisawy, 1960; Holland et al., 2004). This is especially the case for Cassiopea, where analysis based solely on morphological characters is challenging because morphological differences between species are usually subtle and a number of features vary between stages of growth and possibly habitat (Hopf & Kingsford, 2013; Maggio et al., 2019). As a result, it has been suggested that an integrative approach, using both morphological and genetic data will provide more reliable taxonomic separation (Arai et al., 2017; Dawson, 2003; Holland et al., 2004; Maggio et al., 2019).

Molecular study has often revealed unrecognised species in many marine taxa, suggesting that marine biodiversity is higher than previously thought, and speciation is more frequent than originally recognised (Dawson & Jacobs, 2001; Knowlton, 2000). For example, the scyphozoan, Aurelia aurita (Linnaeus, 1758), long thought to be a single widespread species based on morphology has been revealed, based on molecular data, to be a complex of at least 28 species (Dawson & Jacobs, 2001; Lawley et al., 2021). One of the first molecular studies of Cassiopea focused on Hawaiian fauna using a single gene (mitochondrial cytochrome c oxidase I, Holland et al., 2004), and tentatively concluded that there were six species including: (1) C. frondosa, which originates from the western Atlantic and at that time considered by Holland et al. (2004) to be the only morphologically well characterised species; (2) C. andromeda, initially reported from the Red Sea and subsequently the Western Atlantic; (3) C. ornata, reported from Indonesia, Palau and Fiji; and (4–6) species that were not associated with named species based on their morphological characters. Subsequently, genetic analysis has been used as a tool for identifying species of Cassiopea, such as C. andromeda in shrimp farms in Brazil (Thé et al., 2020b) and from Italy (Maggio et al., 2019), respectively. Additionally, utilising genetic techniques, new species have been identified, including two different lineages from Palau (Cassiopea sp.5 and sp.6, Arai et al., 2017), which were not sequenced by Holland et al. (2004). A recent synoptic phylogenetic study of Cassiopea (Gamero-Mora, 2020) recognised at least 17 species of which only six can be associated with formal published names, the most recently described being C. mayeri and C. culionensis (Gamero-Mora et al., 2022; Gamero-Mora, 2020). The identity of at least six named species is currently ambiguous, indicating significant revision of the genus is required (Gamero-Mora et al., 2022; Gamero-Mora, 2020).

In Australia, Cassiopea has typically been recorded from sub-tropical and tropical latitudes, occurring north of 27°58′S on the east coast and 16°08′S on the west coast, with the exception of an apparently introduced population established near a warm water outlet from a power station at Angas Inlet, Adelaide, South Australia (approximately 34°48′S, 138°32′E, Keable & Ahyong, 2016; Southcott, 1982, Fig. 1). To date, four named species of Cassiopea (C. andromeda, C. maremetens, C. ndrosia, C. ornata) and two undescribed species have been reported from Australia (Gershwin, Zeidler & Davie, 2010; Keable & Ahyong, 2016). Cassiopea maremetens, however, is the only species described from Australia (type locality: Pelican Waters, Queensland, 26°49′42″S, 153°06′48″E); other Australian species were described from elsewhere. To date no genetic data for C. maremetens have been available, but it morphologically closely resembles C. andromeda and C. ndrosia (Gershwin, Zeidler & Davie, 2010; Keable & Ahyong, 2016).

Keable & Ahyong (2016) reported a southward range expansion of two species of Cassiopea on the east Australian coast into New South Wales, identifying C. cf. maremetens in Wallis Lake (32°11′45″S, 152°29′56″E) and C. ndrosia in Lake Illawarra (34°31′36″S,150°51′53″E). A further southern population of Cassiopea was discovered in 2017 in Lake Macquarie (33°04′00″S, 151°32′42″E), approximately mid-way between Lake Illawarra and Wallis Lake (Rowe et al., 2022b, Fig. 1). This raises questions about the identity of the species in Lake Macquarie and from where it may have originated. This is especially important because of the invasive potential of Cassiopea and its environmental impacts.

This study aims to determine the identity of the species of Cassiopea occurring in Lake Macquarie using molecular and morphological data, and to re-assess the taxonomic status of C. maremetens in relation to Cassiopea from New South Wales.

Methods

Morphological analysis

Results from the molecular analysis were used to inform specimen sampling for morphometric analysis. A suite of morphological traits were identified and measured following those examined by Morandini et al. (2017), Mayer (1910), Kramp (1961), Hummelinck (1968), Gershwin, Zeidler & Davie (2010), Keable & Ahyong (2016), Jarms et al. (2019). Morphological observations (Fig. 2) were made using a magnification lamp and dissecting microscope. In most cases the exumbrella diameter was measured across the widest point to the nearest millimeter and used to compare size ratios of different features between specimens. However, some specimens have a brittle exumbrella that would not fully open, in which case their condition was noted. Exumbrella diameter, overall height and oral disc height were measured with the oral arms of the specimen lying on top of their exumbrella and with the aboral surface of the exumbrella oriented in the ventral position as when the specimen is naturally at rest on the substrate when encountered in the field (i.e., the typical ‘upside-down’ position). Overall height and oral disc height was measured from the base of the exumbrella and the intersection of oral disc with the bell, to the top of the oral disc. The number of rhopalia and lappets, and the number of lappets per paramere (i.e., between two successive rhopalia, Gamero-Mora et al., 2022) were counted and their shape noted (i.e., round or flat edge, each lappet distinct with grooves between them or connected with a smooth edge, short or long). While the shape and colour of large appendages have been found uninformative in identifying species of Cassiopea in other analyses (Gamero-Mora, 2020), it was observed that their position and size consistently differed between populations occurring in this study on the east coast of Australia. Therefore, the number and shape of large appendages along the oral arms and on the oral disc were recorded. We also measured the length of largest appendage on the oral arm and oral disc from the base to the tip, as well as the width at the midlength. Additionally, the specimen was inverted so that the dorsal surface of the exumbrella was exposed, and the exumbrella was folded back so the oral arms were visible, allowing the length of the oral arms to be recorded from the proximal base at the oral disc to the distal tip of the main trunk. The main oral arm trunk and lateral oral arm branching patterns were also recorded as this is considered to be useful in diagnosing species of Cassiopea (Gamero-Mora, 2020), with three different patterns observed in this study: 1, alternating — the lateral branches switch sides and are separated along the main oral arm trunk; 2, pinnate—the lateral branches are arranged on either side of the main oral arm trunk in pairs opposite each other; 3, bifurcating—the main trunk of the oral arm is divided into two subequally broad distal branches (in this case the distance from the oral disc to the proximal base of the bifurcation, and also whether each branch was equal in length, was recorded).

Standardisation of body size

To ensure that all count data were not skewed by body size, a regression was completed for each continuous variable against exumbrella diameter to determine if there was a positive relationship. If a significant relationship was detected, the variable was divided by the exumbrella diameter for each individual. If a significant relationship was still detected, the z-score (Curtis et al., 2016) was calculated for each individual using the following formula:

$$Z={\displaystyle \frac{x-mean}{standarddeviation}}$$where x is the continuous variable for a specimen and after which, all data was standardised.

Morphometric analysis

To determine if there was any clustering separating putative species based on morphological characters, and if this differed between populations, a non-metric multidimensional scaling (nMDS) was constructed based on a Bray-Curtis similarity matrix using both the continuous data that was standardised for bell diameter, and categorical variables (i.e., oral arm branching pattern; ring canal presence; distribution of large appendages; shape of subgenital pit; and shape of oral arm). This was completed using both the ‘vegan’ package and ‘ggplot2’ in R (v.4.1.1.) (R Development Core Team, 2021). To test for morphological differences a one-way permutation multivariate analysis of variance (PERMANOVA) was completed, with putative species as the fixed factor (3-levels: presumptive C. xamachana, Cassiopea sp.3, Cassiopea sp.2, as listed in Table S3). Additionally, a Ward hierarchical clustering (Cluster) analysis was undertaken to determine morphological similarities between individual samples. Any morphological differences between populations within species for putative C. xamachana and Cassiopea sp.3 were tested using one-way PERMANOVAs with the location of the populations as a fixed factor (3-levels for each species). If there was a significant difference between groups of specimens, a cluster analysis was completed to determine how individuals clustered across populations and in which localities these are morphologically similar.

To establish which features distinguish putative species, a similarity percentage analysis (SIMPER) was applied using the ‘vegan’ package, and the six most influential features were identified.

Results

Genetic analysis

Identification of the Lake Macquarie population

The ML tree (Fig. 3) based on COI of Cassiopea from all sampled localities in Lake Macquarie, Wallis Lake, Pelican Waters, Gold Coast and Moreton Bay formed a strongly supported clade (bootstrap support 100%); all were genetically identical (K2P ± S.E.: 0.00 ± 0.00, Table S4) suggesting they represent a single species, distinct from those of Lake Illawarra (mean between populations K2P ± S.E.: 0.318 ± 0.00), Port Hacking (0.318 ± 0.00), Coombabah Creek (0.324 ± 0.00), and the Northern Territory (0.32 ± 0.00), which were closely related to each other (mean within species K2P ± S.E.: 0.021 ± 0.00). Additionally, the Lake Macquarie specimens differed from those from South Australia (0.078 ± 0.00), Lizard Island (0.294 ± 0.00), and Port Douglas (0.273 ± 0.00). The bTP analysis for species delimitation estimate the presence of six to 36 species with a mean of 21.64. Five species are recognised herein, including Cassiopea from Lake Macquarie, Wallis Lake and Pelican Waters as one species, those from Lake Alexander, Lake Illawarra, Port Hacking and Coombabah Creek as a second species, and each of the populations from Angas Inlet, Port Douglas and Lizard Island, as separate species (see Discussion section and Fig. 1).

Comparison of results

The global ML tree (Fig. 4) recovered the Lake Macquarie, Wallis Lake and Pelican Waters specimens in the same clade and genetically invariant, with low divergence from populations in Hawaii, Brazil, Panama and the Florida Keys (mean within species K2P ± S.E.: 0.016 ± 0.00, Table S5), previously identified as Cassiopea xamachana (Holland et al., 2004; Gamero-Mora et al., 2019; Stampar et al., 2020, S2, see Discussion). The low COI divergence suggests that these populations from different localities all represent the same widespread species. Additionally, specimens from Lake Illawarra, Coombabah Creek, Port Hacking and the Northern Territory (herein referred to as Cassiopea sp.3) form a separate clade and are closely related to another species from Japan, Hawaii and Papua New Guinea (Fig. 4, Table S5). The bTP analysis for species delimitation indicates an estimate of 16 to 38 species with a mean of 25.13.

Morphometric analysis

The nMDS ordination of the specimens of Cassiopea examined is illustrated in Fig. 5. The stress level associated with this two-dimensional plot was 0.176, demonstrating that there were some morphological characters distinguishing the species (Dexter, Rollwagen-Bollens & Bollens, 2018). The nMDS ordination plot formed separated groups based on morphological dissimilarities (Fig. 5). The PERMANOVA confirmed that there are significant morphological differences between species (R² = 0.395, pseudo-F = 30.089, p < 0.01). Additionally, with the exception of three specimens of Cassiopea sp.3 (AM G.20076 from Port Hacking, G.20060 from Coombabah Creek and AM G.18075 from Lake Illawarra) and two specimens of Cassiopea sp.2 (AM G.17387 and AM G.17370) from Papua New Guinea, the cluster analysis confirmed these results (Fig. S6), and grouped specimens into two morphological groups, with material corresponding to putative Cassiopea sp.3 and Cassiopea sp.2 in the first cluster and presumptive C. xamachana in the second. The PERMANOVA between Australian populations of Cassiopea from Lake Macquarie, Wallis Lake and Pelican waters indicates there are morphological differences between locations (R² = 0.077, pseudo-F = 2.587, p < 0.05). The follow-up cluster analysis (Fig. S7A) indicated no C. xamachana location clusters driving this significance with the two significant clusters containing specimens from all three locations. However, morphological differences were detected between populations of Cassiopea sp.3 from Lake Illawarra, Coombabah Creek, Port Hacking, and Lake Alexander (R² = 0.498, pseudo-F = 6.605, p < 0.001). Additionally, the follow up cluster analysis (Fig. S7B) confirmed morphological clusters between locations of Cassiopea sp.2, including cluster 1 containing specimens from the Port Hacking, cluster 2 from Coombabah Creek with two specimens from the Port Hacking, cluster 3 from Northern Territory, with one specimen from Lake Illawarra, and cluster 4 containing specimens from Lake Illawarra.

SIMPER indicated the three most informative features contributing to separation of putative C. xamachana and Cassiopea sp.3 according to their cumulative contribution are: the number of large appendages on the oral disc; oral arm branching pattern; and length of large appendages on the oral arm (Table 2, Figs. 6–9). Branching pattern is also a distinguishing feature between C. xamachana and Cassiopea sp.2, as well as between Cassiopea sp.2 and Cassiopea sp.3, along with number of ring canals and large appendage distribution (Table 2). The features that were considered less useful when distinguishing between taxa include the shape of the subgenital pit, the number of ring canals, and the shape of the oral arm.

Table 2:

SIMPER results showing top three cumulative contributions of morphological characters that distinguish specimens.

Average is the contribution to dissimilarity, Standard deviation of dissimilarity, and Cumulative Sum ordered cumulative contribution.

Comparison of putative species	Morphological feature	Average	Standard deviation	Cumulative sum	Figure
C. xamachana–C. sp.3	Number of large appendages on oral disc	0.0070329	0.0054158	0.06399	8A
	Oral arm branching pattern	0.0065736	0.0053396	0.12380	9
	Length of large appendages on oral arm	0.0058753	0.0036507	0.17726	8B
C. xamachana–C. sp.2	Ring canal presence	0.0109182	0.012637	0.08762
	Distribution of large appendages on oral arm	0.0097679	0.006158	0.16601
	Oral arm branching pattern	0.0091168	0.006856	0.23918	9
C. sp.3–C. sp.2	Ring canal presence	0.011149	0.012803	0.09511
	Distribution of large appendages on oral arm	0.008733	0.005651	0.16960
	Oral arm branching pattern	0.007707	0.005118	0.23534	9

DOI: 10.7717/peerj.19669/table-2

Discussion

Although the genus Cassiopea is easily recognised, the species have had a confused taxonomic history owing to subtle morphological distinctions and general morphological conservatism in the genus (Holland et al., 2004; Hopf & Kingsford, 2013; López-Figueroa, Stoner & Hallock, 2024; Maggio et al., 2019). This has resulted in a need for molecular data combined with morphology to identify species of Cassiopea in new locations (Holland et al., 2004; Maggio et al., 2019). Additionally, some species of Cassiopea are invasive, with new distribution records around the world, and so correctly identifying the species of Cassiopea is crucial to track and manage their spread (Holland et al., 2004; Keable & Ahyong, 2016; Maggio et al., 2019; Morandini et al., 2017; Thé et al., 2020a).

Sequences of Cassiopea from eastern Australia (Lake Macquarie, Wallis Lake and Pelican Waters) group with, and are indistinguishable at species level from those from Hawaii, Brazil, Palau, Panama, Florida Keys and an additional locality in the northwest Pacific Ocean (Fig. 4). Terminals within this clade are referable to C. xamachana based on genetic comparisons, morphology, and redescription of material that is to be designated as the neotype of the species (Gamero-Mora et al., 2019; Gamero-Mora, 2020; Stampar et al., 2020). However, Cassiopea occurring in Lake Macquarie and Wallis Lake, namely C. xamachana, are also genetically indistinguishable from those from Pelican Waters. This result is particularly significant because Pelican Waters is the type locality of C. maremetens (Gershwin, Zeidler & Davie, 2010). Morphological congruence was also found between specimens from Lake Macquarie and Pelican Waters, including the holotype of C. maremetens. This is the first time that specimens morphologically corresponding to C. maremetens from the type locality of the species have been evaluated based on genetic data.

This provides strong evidence that C. maremetens is conspecific with C. xamachana, with the latter having nomenclatural priority as the older name. This was confirmed by morphological revision of type material of C. maremetens and comparison with additional specimens including topotypes (see Taxonomy and Morphometric Analysis sections). As such, we formally synonymise C. maremetens with C. xamachana, below. Additionally, material from Panama in this clade previously identified by Daglio & Dawson (2017) as C. frondosa appears to be a misidentification and is actually C. xamachana. Conversely, a specimen from the same study identified as C. xamachana and also from Panama was placed here in the C. frondosa clade (Daglio & Dawson, 2017) and is apparently C. frondosa based on the identity assigned in other studies to the members of this clade.

Cassiopea xamachana was first described by Bigelow (1892) from the Caribbean Sea and has subsequently been reported from a wide variety of locations (see Remarks in Taxonomy section). This species has been taxonomically confused with C. andromeda (type locality: Red Sea), both species apparently overlapping in distribution in Florida with a third species, C. frondosa (type locality: Caribbean Sea, Muffett & Miglietta, 2023). Our study supports the results of Gamero-Mora (2020) and Muffett & Miglietta (2023) in recognising C. xamachana as more closely related to C. andromeda (type locality: Red Sea) with a mean pairwise divergence of 7.2%, than to its Caribbean congener, C. frondosa (mean pairwise divergence: 19%). Some studies suggest that C. xamachana and C. andromeda might be conspecific given their morphological and genetic similarities (Arai et al., 2017; Gamero-Mora, 2020; Holland et al., 2004; Jarms et al., 2019), but Gamero-Mora et al. (2022) treated these as separate species because of significant divergence and reciprocal monophyly on the basis of 28S ribosomal sequences; this was supported by Muffett & Miglietta (2023). Like C. xamachana, C. andromeda has subsequently been reported from the tropical and subtropical western Atlantic, Mediterranean Sea, the Indo-Pacific (including Australia, Gershwin, Zeidler & Davie, 2010; this study) and recently, the eastern Atlantic (Gueroun et al., 2024). For these two species, geography is unhelpful in species identification given that both can be sympatric in parts of their range as a result of both natural and artificial processes, and the additional possibility that other species may be present (Fitt et al., 2021; Muffett & Miglietta, 2023).

Specimens of a second species occurring in eastern Australia analysed here from Lake Illawarra, New South Wales, and Coombabah Creek, Queensland, are found to be closely related to specimens from Japan (Abboud, Daglio & Dawson, 2018), Papua New Guinea and Hawaii (Holland et al., 2004), reported as Cassiopea sp.3. While there is some genetic variation between Australian populations, including Lake Alexander, NT, and those from overseas (mean pairwise divergence: 6.7%), they are here considered a single species due to the pairwise divergence being lower than the minimum between closely related species recognised by Gamero-Mora et al. (2022) (i.e., 7.7% between C. xamachana and C. andromeda). Additionally, while Keable & Ahyong (2016) identified the population in Lake Illawarra as C. ndrosia, based on morphology and previous records using this name, the morphological features of these populations require comparison with those from the type locality of C. ndrosia, Suva Harbour, Fiji. In addition to more detailed morphological analysis, it is also recommended that future studies consider use of a wider suite of markers, especially those from the nuclear genome to allow for a more comprehensive and robust understanding of species distinctions and their relationships.

Morphometric analysis detected significant morphological differences between the two species occurring on the east coast of Australia and also Cassiopea sp.2 from Papua New Guinea. These consistent differences corroborate their previous treatment as separate species (Chiaverano, Bayha & Graham, 2016; Holland et al., 2004; Lessios, 2008), which is also indicated by the genetic analysis in this study. Three main features are significant in the morphometric separation of C. xamachana and Cassiopea sp.3 are: (1) the number of large appendages on the oral disc, which is much higher in Cassiopea sp.3 (at least 1 but up to 14 in medusae >10 cm), with C. xamachana having a maximum of two large appendages; (2) the oral arm branching pattern, which is usually alternating for C. xamachana, but a combination of alternating, bifurcating and pinnate for Cassiopea sp.3; (3) the length of the large appendage on the oral arm (average of 2.6 cm, which is 0.2 bell diameter, compared to 1.4 cm for Cassiopea sp.3, which is 0.12 bell diameter). There was some overlap on the nMDS plot, which represents interspecific variation.

Characters of the large appendages in Cassiopea are shown here to be useful and reliable in separating some species. They are believed to have two main functions. First, they provide additional surface area for zooxanthellae, and second, they contain nematocysts in clusters known as cassiosomes, which are used for feeding to capture prey or released in defence (Ames et al., 2020; Larson, 1997; Stampar et al., 2020). Historically, clear and consistent information about large appendages has not been included in descriptions of Cassiopea, and as a result there is no standardised terminology, leading to taxonomic confusion (Gamero-Mora, 2020). Whereas, the present study recorded variations in size, colour, and shape of large appendages within species, their distribution and the location of the longest large appendage proved particularly useful for comparing Australian populations of C. xamachana and Cassiopea sp.3.

The characters that we identify as consistent across C. xamachana populations along the east coast of Australia are also consistent with the original description of specimens from Jamaica, Caribbean Sea, by Bigelow (1892) and the revision of this species by Gamero-Mora (2020), respectively. These features include generally five lappets per paramere; ribbon shaped large appendages located along the oral arms, and one on the bifurcation of each branch. However, Bigelow (1892) and Gamero-Mora (2020) record 5–13 large appendages on the oral disc, which is far more than we found in Australian specimens. Conversely, Gamero-Mora (2020) also record variations between populations of C. xamachana, noting that the Atlantic Mexican population only has one appendage located on the oral disc if present at all, which is consistent with the Australian material observed here. Additionally, characters highlighted in the original description of C. maremetens by Gershwin, Zeidler & Davie (2010) (see Taxonomy section) and comparison with other species by Gamero-Mora (2020) are consistent with the distinguishing features identified in this study, including five lappets per paramere, up to two large appendages on the oral disc, and a leaf shaped large appendage on the bifurcation of the oral arm. While Gershwin, Zeidler & Davie (2010) also recorded the absence of large appendages on some of the paratypes of C. maremetens, those specimens are not from the type locality, but from localities within Moreton Bay and without molecular data, and so were not examined in this study—these might represent other species. As a result, molecular comparisons of specimens from these localities need to be made with known C. xamachana and Cassiopea sp.3 populations to corroborate the identification of these paratypes.

Keable & Ahyong (2016) identified the species occurring in Lake Illawarra as C. ndrosia; in comparison with the taxonomic revision by Gamero-Mora (2020) and the specimens in this study assigned to Cassiopea sp.3, some of the features are consistent with this identification as C. ndrosia, including the rhopalia (14–23) counts and the presence of large appendages on the oral disc, which are conversely absent from the oral arms. Despite morphological similarities between Cassiopea sp.3 and the description of C. ndrosia by Gamero-Mora (2020), a detailed morphological data and molecular data are not yet available for specimens definitively identified as C. ndrosia (type locality: Suva Harbour, Fiji). Therefore, both genetic and morphological comparisons need to be made between Cassiopea sp.3 from Australia, Japan, Hawaii, Papua New Guinea, and specimens from the type locality of C. ndrosia, Suva Harbour, Fiji, before a positive match for Cassiopea sp.3 can be made with an available taxonomic name.

Although further revisionary study of Cassiopea occurring in Australia is needed, present confirmation of the presence of C. xamachana in Australia is significant given the attention this species has received at other localities as an invasive species. The native range of C. xamachana (whether the tropical western Atlantic or the central western Pacific) warrants further study, but the minimal genetic diversity in eastern Australia (a single haplotype; Fig. 3) in addition to its apparently recent appearance there suggests that is a recent arrival, more so because Cassiopea are conspicuous wherever they occur. Certainly, the southward expansion by C. xamachana and its localised blooms indicate that it is currently invasive in New South Wales coastal lakes (Gershwin, Zeidler & Davie, 2010; Keable & Ahyong, 2016; Rowe et al., 2022b). As a probably new arrival, rather than a native species increasing its range, the expanding distribution records within Australia are of greater importance than previously recognised. Additionally, further study to determine vectors by which this species may be being translocated, including whether Cassiopea is naturally expanding its range, or whether it is human-mediated introductions.

Taxonomy

Order RHIZOSTOMEAE Cuvier, 1800

CASSIOPEIDAE Tilesius, 1831

Cassiopea Peron & Lesueur, 1810

Cassiopea xamachana Bigelow, 1892

Figures 8–10.

Cassiopea xamachana Bigelow, 1892: 212–221.—Bigelow, 1893: 301.—Bigelow, 1900: 191, figs A–L, pl. 31–38.—Mayer, 1910: 499–735, pl. 56–76.—Kramp, 1961.—Hummelinck, 1968: 1–57.—Holland et al., 2004: 1119.—Morandini et al., 2017: 321.—Ohdera et al., 2018: 1.—Gamero-Mora et al., 2019: 1.—Jarms et al., 2019: 504.

Cassiopea maremetens Gershwin, Zeidler & Davie, 2010: 91, fig. 6C–F.—Templeman & Kingsford, 2015: 1–8.—Epstein, Templeman & Kingsford, 2016: 340–346.—Jarms et al., 2019: 492.—Gamero-Mora, 2020: 113, fig 43.—Rowen, Templeman & Kingsford, 2017: 143–148.—McKenzie, Templeman & Kingsford, 2020:1–7.—Templeman, McKenzie & Kingsford, 2021: 1. [New synonymy]

Cassiopea cf. maremetens.—Keable & Ahyong, 2016: 26, figs 2E–H, 3C–D, 4D–F.

Cassiopea sp.—Rowe et al., 2022a: 2.—Rowe et al., 2022b: 1.

Cassiopea medusa.—Durieux et al., 2023: 9 [nomen nudum; not C. medusa Light, 1914, erroneous citation of Rowe et al. (2022a: 2) who indicate “Cassiopea medusae”, i.e., medusae of Cassiopea sp., subsequently identified here as C. xamachana].

?Cassiopea andromeda.—Stephenson, 1962: 94 [doubtfully C. andromeda Forskål, 1775].

Type material of C. maremetens examined. Holotype: QM G.326486, female (17.5 cm diameter), off Lamerough Canal, Lake Magellan, Pelican Waters, Queensland, Australia, 26°49′47″S, 153°6′36″E, D. Potter and G. Cranitch, 24 May 2007. Paratypes: QM G.6645, eight specimens (9.8, 10, 10.9, 10.3, 11, 11.5, 11.5, 11.5 cm), Mud Island, Moreton Bay, Queensland, Australia, 27°19′47″S, 153°15′0″E, C. Wallace, 4 August 1972. QM G.327932, two females (8.8, 17.2 cm), off Lamerough Canal, Lake Magellan, Pelican Waters, Queensland, Australia, 26°49′47″S, 153°6′36″E, D. Potter and G. Cranitch, 24 May 2007. QM G.327969, two females (11.9, 14.5 cm), estuary on NW side of Bentick Island, Queensland, Australia, 17°3′35″S, 139°29′24″E, P. Davie, 20 November 2002.

Additional material examined (all from Australia). Pelican Waters, Queensland: AM G.20068-20069, two females (15.5, 16.1 cm), 26°50′01″S, 153°06′44″E, C.E. Rowe, 10 March 2021. Gold Coast, Queensland: QM G.339123–339125, three specimens (5.9, 7.7, 12.1 cm), 28°3′S, 153°24′26″E, M. Ekins and I. Jamieson, 8 August 2019. QM G.339126–339130, five females (6.7, 7.2, 8, 10.3, 17.3 cm), 28°10′S, 153°24′37″E, M. Ekins and I. Jamieson, 8 August 2019. SeaWorld Culture, Queensland: AM G.18699–18701, three specimens (6.1, 6.5, 10.4 cm), most probably originating from a small inlet on southern end of South Stradbroke Island, Gold Coast Council Region, 25°55′3″S, 153°25′15″E, 22 January 2019. Wallis Lake, New South Wales: AM G.18137–18139, 13 specimens (6.4, 7.7, 7.7, 7.7, 9.2, 10.4, 10.9, 11.2, 11.3, 12.1, 12.7 cm), in channel splitting Godwin Island approximately one-third distance from southern shore, 32°11′45″S, 152°29′55″E, R. Pearce, 15 August 2014. AM G.18143–18156, 12 specimens (2.9, 3.6, 4.4, 5.2, 5.6, 7.2, 8.4, 8.8, 8.8, 9.4, 9.6, 9.7, 10.7 cm), behind Smugglers Cove Caravan Park, Pipers Creek, “The Keys”, 32°12′0″S, 152°30′39″E, R. Pearce, 18 September 2014. AM G.18181–18183, four specimens, inlet on south-east side of Mather Island, 32°11′26″S, 152°29′36″E, S.J. Keable and A.D. Hegedus, 28 April 2015. AM G.18184, one specimen, Pipers Creek within Smugglers Cove Caravan Park, 32°11′58″S, 152°30′39″E, S.J. Keable and A. Murray, 30 April 2015. AM G.18736–18755, 20 females (8.9, 11, 12, 12.5, 12.8, 13.1, 13.3, 15, 15.1, 15.1, 16.7, 17.3, 18.7, 19.1, 19.4, 19.4, 20.8, 20.9, 22.3, 24 cm), Pipers Creek within Smugglers Cove Caravan Park, 32°11′58″S, 152°30′39″E, S.J. Keable and C.E. Rowe, 10 May 2019. Lake Macquarie, New South Wales: AM G.18362–18365, 12 specimens (7.1, 10, 12.6, 13.1, 13.3, 13.4, 16.7, 17, 17.4, 17.5, 19.6, 19.7 cm), Lake Petite, 33°06′59″S, 151°32′04″E, S.J. Keable, D.J. Keable, S. Jones, D. Jones, and E.M. Keable, 4 June 2017. AM G.18428, one specimen (13.4 cm), Lake Petite, 33°07′00″S, 151°31′58″E, S.J. Keable and A. Hay, 9 February 2018. AM G.18528, 1 specimen (6.1 cm), Karignan Creek, 33°10′36″S, 151°34′03″E, C.E. Rowe and S.J. Keable, 16 May 2018. AM G.18711–18712, two specimens (11.9, 12.4 cm), Mannering Bay, 33°09′28″S, 151°31′41″E, C.E. Rowe and S.J. Keable, 7 March 2019. AM G.18716–18723, eight females (10.3, 14.3, 12, 15.5, 16.4, 17, 19.6, 20 cm), Karignan Creek, 33°10′32″S, 151°34′00″E, S.J. Keable and C.E. Rowe, 6 May 2019. AM G.18724–18728, five females (11.3, 12, 12.2, 12.9, 14.4 cm), creek north of Kilaben Creek, 33°01′43″S, 151°35′01″E, S.J. Keable and C.E. Rowe, 9 May 2019. AM G.18729–18735, seven females (14.2, 16.1, 17.2, 19.2, 19.7, 19.8, 20.9 cm), Lake Petite, 33°07′03″S, 151°32′06″E, S.J. Keable and C.E. Rowe, 9 May 2019.

Comparative material examined. Cassiopea sp.3: Northern Territory, Australia: AM G.17363 and G.17374, three specimens (6.3, 6.8, 6.8 cm), Lake Alexander, Darwin, 12°24′S, 130°49′E, M. Dawson, 15 November 2003. Queensland, Australia: AM G.20057–20061, five females (14.9, 15.4, 16.2, 16.3, 18.2 cm), Kangaroo Avenue, Coombabah Creek, Gold Coast, 27°05′26″S, 153°22′57″E, C.E. Rowe and J. Lawley, 8 March 2021. AM G.20064–20067, four specimens (2.3, 5.1, 9.9, 10.7 cm), SeaWorld culture originating from Coombabah Creek and South Stradbroke Island, Gold Coast Region, 25°55′3″S, 153°25′15″E, 9 March 2021. AM G.13568, three specimens (10.1, 12.2, 13.3 cm), off Hayman Island, Whitsunday Passage, 20°03′S, 148°53′E, JA. McNeill, 17 April 1934 (material referred to by Stiasny (1931) and Keable & Ahyong (2016) as C. ndrosia). New South Wales, Australia: AM G.18075, one specimen (9.2 cm), canal through jetties by the lake at Windang Road, Lake Illawarra, 34°31′36″S, 150°51′52″E, M. Cameron, 8 May 2013 (material referred to by Keable & Ahyong (2016) as C. ndrosia). AM G.20077, 11 specimens (3, 4.2, 5.4, 6.9, 7.2, 7.3, 8.2, 9.8, 10.5, 10.8, 15.1 cm), canal through jetties by the lake at Windang Road, Lake Illawarra 34°31′36″S, 150°51′52″E, S.J. Keable and C.E. Rowe, 1 June 2021. AM G.20076, two specimens (12.7, 12.8 cm), channel between rocky shore and sand spit, north-east of entrance to Cabbage Tree Basin, Port Hacking 34°04′44″S, 151°07′58–E, S.J. Keable and C.E. Rowe, 31 May 2021.

Cassiopea sp.2: Papua New Guinea: AM G.17370 and G.17385, six specimens (4.6, 7.3, 7.7 8.9, 9,10.5 cm), outer slope, west side of Mascot Channel mouth, 2°40′04″S, 150°25′58″E, P.L. Colin, 3 July 2003. AM G.17387, one specimen (5.2 cm), atoll −70 nautical miles south-south-east of Manus Island, Sherburne Reef, 3°19′59″S, 148°01′03"E, D. de Mara, 20 June 2002. Queensland, Australia: AM G.18344, one specimen (6.3 cm), north-east coast, Lizard Island, 14°40′01″S, 145°27′37″E, A. Hoggett, 21 February 2016.

Cassiopea andromeda: South Australia: SAM H3568, H3577–78 and H3581, four specimens (6.2, 6.2, 7.9, 9.7 cm), boat ramp, Garden Island Yacht Club, Garden Island, Angas Inlet, 34°48′11″S, 138°31′55″E, M. Bossley and A. Crowther, 4 May 2022.

Description. (Where variation present, value for holotype of C. maremetans given in brackets). Exumbrella: marginal outline circular; aboral surface mostly flat with small concavity; maximum diameter 24 cm, mean 11.5 cm (holotype: 17 cm); height 0.2–2.7 cm (0.4 cm), mean 0.9 cm. Colour pattern brown, yellow, green (greenish yellow). Markings include small white spots around bell margin, triangle facing towards each ocellus on live specimens (markings lost in preservation). Rhopalia 13–23 (19), mean 15, located in incised notches; ocelli present. Marginal lappets 32–120 (104), mean 83 depending on the condition of the specimen, with 3–7 per paramere (4–6), not always distinct, distal edge with rounded low lobes; 1–5 (3) velar lappets located between two ocular lappets. Ring canals 1 in total, raised.

Oral disc: 0.2–2 cm height, with a mean of 0.94 cm, 0.5–8.2 cm width, and with a mean of 3.88 cm, typically 1.6–5.4 × the bell diameter, with a mean of 0.4 × bell diameter. Subgenital pit circular or rhomboid, 0.1–0.9 cm width, with 0.65 cm mean, 0.09–0.58 × oral disc height, with 0.3 mean. Large appendages present on specimens >8 cm; 1 or 2 in centre of oral disc (1), fusiform, 0.7–3.4 cm in length (2.5 cm), averaging 1.3 cm, 0.17–0.67 × oral disc width, but typically 0.25 × oral disc width, width of large appendage 0.06–0.4 × length of large appendage (0.4), typically 0.27 length of large appendage.

Oral arms: 7–10 (8), usually 8 (except AM G.18733, G.18728, QM G.327932, G.6645, G.32769). 0.9–14.5 cm in length (12.3) with mean of 6.38 cm, 0.75 to 1.54 × bell radius (1.5 × bell radius) with mean 1.2 × bell radius, extending radially beyond bell margin, cylindrical in shape. Lateral branches 3–7 per oral arm (4 or 5), cylindrical; alternating branching pattern; secondary lateral branches with alternating branching pattern of equal strength. Trunk of oral arm ending in unequal bifurcation. Small appendages numerous, flat, fusiform, transparent, distributed evenly along oral surface of oral arm and lateral branches. Large appendages present; largest located at bifurcation of oral arm, 0.25.0 cm in length (1.7 cm) with mean of 2.50 cm, 0.07–0.63 × oral arm length with mean 0.3 × oral arm length, and width 0.05–0.36 × length, but typically 0.22 length. Number of large appendages on oral arm varying with size, with two large appendages near distal bifurcation in smaller specimens (e.g., AM G.18754 (11 cm), G.18744 (12.8 cm), G.18723 (12 cm)) and up to 17 evenly distributed along the oral arm in larger specimens (e.g., AM G.18365 (17 cm) and G.18362 (19.7 cm), holotype QM G.326486 with 2, 1 located at distal bifurcation and other half-way along oral arm, but this may be an artefact of damage, see Remarks), always present at distal bifurcation, fusiform.

Gonads: Always visible, cruciform, as mature gonads indicating sex, but definition varying with size and condition of preserved specimen; developed in specimens >10 cm in diameter.

Remarks

The diagnostic characters of Australian specimens, including the type material of C. maremetens and additional material from the type locality, are indistinguishable from those of C. xamachana from the western Atlantic (Bigelow, 1892). These include the number of lappets per paramere (4–6) and their indistinct, rounded shape; the alternating lateral branches along the oral arm, which end with an unequal bifurcation; and the longest large appendage located at the bifurcation in the oral arm, with the number of large appendages on the oral arm increasing with size (1–17), with maximum two located at the centre of the oral disc. These features are consistent across all specimens examined from Wallis Lake, Lake Macquarie and Pelican Waters, which are also genetically invariant in COI. Additionally, the morphometric analysis supports these as consistent features distinguishing C. xamachana from Cassiopea sp.3. As such, C. maremetens and C. xamachana are indistinguishable and we recognise the former as a junior synonym of the latter.

Conclusion

The species of Cassiopea occurring in Lake Macquarie, Wallis Lake and Pelican Waters (type locality of C. maremetens) is genetically and morphologically referable to C. xamachana. We provide a detailed description of Australian C. xamachana, including a comparison with the type and topotypic material of C. maremetens, synonymised herein. Additionally, we provide evidence that a second species, C. sp.3 (previously identified as C. ndrosia), is expanding its range south along the east coast of Australia and identify the morphological features that distinguish it from C. xamachana. As the two species continue to expand their range southwards in eastern Australia, which is expected under climate change scenarios (Rowe et al., 2022a), these diagnostic features will facilitate their identification, especially in monitoring and management of their invasion front.

Supplemental Information
